Titanate coupling agent 102

1. Product overview:

      This product is a yellow or amber translucent viscous liquid with good compatibility with polar materials, soluble in isopropanol, xylene, toluene, mineral oil, plasticizer DOP reaction, insoluble in water, and difficult to hydrolyze.

Corresponding brand abroad: KR-38S of American Kenrich Company;

Chemical name: isopropyl tris(dioctyl pyrophosphate acyloxy) titanate;

Molecular formula: C51H112O22P6Ti;

Molecular weight: 1310;

2. Technical indicators:

     Item Unit Indicator

     Appearance - yellow or amber translucent viscous liquid

     Refractive Index - 1.446

     Density g/ml 1.096

     PH value - 1.5～2

     Flash point ℃ 150

     Decomposition temperature ℃ 240

3,The main purpose:

1. Surface treatment of fillers and pigments

    This product is especially suitable for surface modification of fillers, such as talcum powder, aluminum hydroxide, glass fiber, glass microspheres, powder ash, wood powder, wet clay, fruit stone powder, etc. Many pigments (such as basic lead silicon chrome yellow, carbon black, bisarylate yellow, iron oxide, nickel phthalocyanine blue, red lake and other pigments) can improve their dispersion performance after being treated with this product.

2. Modification effect of various polymer filling systems:

     ① High filling; ② Improve impact resistance; ③ Improve rheology; ④ Ease of processing; ⑤ Flame retardant; ⑥ Reduce viscosity;

⑦Improve physical properties; ⑧Reduce the baking temperature;

⑨Improve chemical stability; ⑩Thixotropy

3. Flame retardant FRP

In the glass fiber reinforced polyester FRP highly filled with aluminum hydroxide, the settlement of the filler can be improved when the initial liquid resin is used, so that the flame retardancy of the product can be improved.

4. Magnetic recording materials and plastic rubber magnets

      The magnetic powder treated with this product can improve its dispersion on the polymer substrate and its adhesion to the polymer, and greatly increase the content of the magnetic powder. Make magnetic recording materials have better fluidity, paintability, higher shear strength, lower magnetic defects, etc.

5. This product is used in the rubber industry to improve the tensile strength, tear strength and elongation at break of rubber products.

4. Dosage and usage:

1. The dosage is 0.5-2.0% of the total amount of pigment or filler, and the recommended dosage is 1.0%. Please experiment with the appropriate dosage.

2. Usage: Spray the coupling agent diluted 1:1 with the solvent and the pigment in the high-speed mixer, continue to stir for 5-15 minutes (depending on the effect), and then discharge the material for later use (pay attention to heat dissipation) or add other additives and The carrier, if milled, may be added at the time of milling.

3. Solvent selection: plastic industry—liquid paraffin (ie white oil); rubber industry—solvent oil or machine oil; paint industry—solvent oil or isopropanol.

5. Packaging, storage and transportation and precautions:

      This product is packed in a 25kg plastic drum, which is moisture-proof, sun-proof, and prevents impurities such as acid and alkali from being mixed in. It is transported as non-dangerous goods and has a limited period of one year.
